SupraPlus

SupraPlus

Lifts smooth objects without damage

Item Number: 2028413
SSAUS ERP Code: SP1000-0x1.5
SupraPlus 1t 1.5m
  • 40% thicker sleeve giving increased durability and up to 4 times longer service.
  • Compact sleeve design achieves a narrower sling than conventional round slings.
  • Sleeve with WLL data woven into sleeve for unmistakable capacity identification.
  • Lightweight and soft – reduced manual handling injuries.
  • Tuff Tag, webbing reinforced encapsulated compliance labels.

Select Model

...

Made in Australia

Made, Tested and Certified.

SupraPlus Round Slings

Lifts smooth objects without damage

Australian Made – Australian Tested – Australian Certified.

  • Sleeve with WLL data woven into sleeve for unmistakable capacity identification.
  • 40% thicker sleeve giving increased durability and up to 4 times longer service.
  • Compact sleeve design achieves a narrower sling than conventional round slings.
  • Raised ribs on sleeve improves gliding characteristics when choking and inproves cut and abrasion resistance.
  • Variable load bearing point for more even wear.
  • Ideal for choke lifting cylindrical objects.
  • Lightweight and soft – reduced manual handling injuries.
  • High strength to weight ratio.
  • Load bearing fibres protected by the outer sleeve.
  • Wide choice of lifting modes.
  • Tuff Tag, webbing reinforced encapsulated compliance labels.
  • Certified to AS 4497:2018.
  • Safety factor 7:1.

For a 10th of a metre, add length to required WLL value e.g. SP2000-0x5.5
For over 8.0m lengths, add length to required WLL value e.g. SP2000-0x12.0

Product Technical Information

  • Safety Factor
    7:1
  • Standards
    AS 4497:2018
  • Temperature Range
    -40⁰C to 100⁰C
  • Dimension L1 max
    60 m
  • Label Protection
    Yes
  • Main Material
    Polyester
  • Packaging Unit (PU)
    pcs
  • Packaging Unit (PU) Content
    1

Technical Drawings

Item Number Item Name WLL kg Contact Width Under Load Weight per Meter Weight Net Dimension L1 min Dimension L1 Colour Contact Thickness Under Load Minimum Load Edge Radius
2028413 SupraPlus 1t 1.5m 1000 kg 36 mm 0.35 kg/m 0.52 kg 0.5 m 1.5 m Purple 6 mm 18 mm
2028414 SupraPlus 1t 2m 1000 kg 36 mm 0.35 kg/m 0.7 kg 0.5 m 2 m Purple 6 mm 18 mm
2028415 SupraPlus 1t 2.5m 1000 kg 36 mm 0.35 kg/m 0.87 kg 0.5 m 2.5 m Purple 6 mm 18 mm
2028416 SupraPlus 1t 3m 1000 kg 36 mm 0.35 kg/m 1.05 kg 0.5 m 3 m Purple 6 mm 18 mm
2028417 SupraPlus 1t 4m 1000 kg 36 mm 0.35 kg/m 1.4 kg 0.5 m 4 m Purple 6 mm 18 mm
2028418 SupraPlus 1t 5m 1000 kg 36 mm 0.35 kg/m 1.75 kg 0.5 m 5 m Purple 6 mm 18 mm
2028419 SupraPlus 1t 6m 1000 kg 36 mm 0.35 kg/m 2.1 kg 0.5 m 6 m Purple 6 mm 18 mm
2028420 SupraPlus 1t 8m 1000 kg 36 mm 0.35 kg/m 2.8 kg 0.5 m 8 m Purple 6 mm 18 mm
2028421 SupraPlus 1t 10m 1000 kg 36 mm 0.35 kg/m 3.5 kg 0.5 m 10 m Purple 6 mm 18 mm
2028422 SupraPlus 2t 1.5m 2000 kg 37 mm 0.5 kg/m 0.75 kg 0.5 m 1.5 m Green 8 mm 24 mm
2028423 SupraPlus 2t 2m 2000 kg 37 mm 0.5 kg/m 1 kg 0.5 m 2 m Green 8 mm 24 mm
2028424 SupraPlus 2t 2.5m 2000 kg 37 mm 0.5 kg/m 1.25 kg 0.5 m 2.5 m Green 8 mm 24 mm
2028425 SupraPlus 2t 3m 2000 kg 37 mm 0.5 kg/m 1.5 kg 0.5 m 3 m Green 8 mm 24 mm
2028426 SupraPlus 2t 4m 2000 kg 37 mm 0.5 kg/m 2 kg 0.5 m 4 m Green 8 mm 24 mm
2028427 SupraPlus 2t 5m 2000 kg 37 mm 0.5 kg/m 2.5 kg 0.5 m 5 m Green 8 mm 24 mm
2028428 SupraPlus 2t 6m 2000 kg 37 mm 0.5 kg/m 3 kg 0.5 m 6 m Green 8 mm 24 mm
2028429 SupraPlus 2t 8m 2000 kg 37 mm 0.5 kg/m 4 kg 0.5 m 8 m Green 8 mm 24 mm
2028430 SupraPlus 2t 10m 2000 kg 37 mm 0.5 kg/m 5 kg 0.5 m 10 m Green 8 mm 24 mm
2028431 Supraplus 3t 1.5m 3000 kg 44 mm 0.6 kg/m 0.9 kg 0.5 m 1.5 m Yellow 10 mm 30 mm
2028432 SupraPlus 3t 2m 3000 kg 44 mm 0.6 kg/m 1.2 kg 0.5 m 2 m Yellow 10 mm 30 mm
2028433 SupraPlus 3t 2.5m 3000 kg 44 mm 0.6 kg/m 1.5 kg 0.5 m 2.5 m Yellow 10 mm 30 mm
2028434 SupraPlus 3t 3m 3000 kg 44 mm 0.6 kg/m 1.8 kg 0.5 m 3 m Yellow 10 mm 30 mm
2028435 SupraPlus 3t 4m 3000 kg 44 mm 0.6 kg/m 2.4 kg 0.5 m 4 m Yellow 10 mm 30 mm
2028436 Supraplus 3t 5m 3000 kg 44 mm 0.6 kg/m 3 kg 0.5 m 5 m Yellow 10 mm 30 mm
2028437 SupraPlus 3t 6m 3000 kg 44 mm 0.6 kg/m 3.6 kg 0.5 m 6 m Yellow 10 mm 30 mm
2028438 SupraPlus 3t 7m 3000 kg 44 mm 0.6 kg/m 4.2 kg 0.5 m 7 m Yellow 10 mm 30 mm
2028439 SupraPlus 3t 8m 3000 kg 44 mm 0.6 kg/m 4.8 kg 0.5 m 8 m Yellow 10 mm 30 mm
2028440 Supraplus 4t 1.5m 4000 kg 52 mm 0.9 kg/m 1.35 kg 1 m 1.5 m Grey 12 mm 36 mm
2028441 SupraPlus 4t 2m 4000 kg 52 mm 0.9 kg/m 1.8 kg 1 m 2 m Grey 12 mm 36 mm
2028442 SupraPlus 4t 2.5m 4000 kg 52 mm 0.9 kg/m 2.25 kg 1 m 2.5 m Grey 12 mm 36 mm
2028443 SupraPlus 4t 3m 4000 kg 52 mm 0.9 kg/m 2.7 kg 1 m 3 m Grey 12 mm 36 mm
2028444 SupraPlus 4t 4m 4000 kg 52 mm 0.9 kg/m 3.6 kg 1 m 4 m Grey 12 mm 36 mm
2028445 SupraPlus 4t 5m 4000 kg 52 mm 0.9 kg/m 4.5 kg 1 m 5 m Grey 12 mm 36 mm
2028446 SupraPlus 4t 6m 4000 kg 52 mm 0.9 kg/m 5.4 kg 1 m 6 m Grey 12 mm 36 mm
2028447 SupraPlus 4t 7m 4000 kg 52 mm 0.9 kg/m 6.3 kg 1 m 7 m Grey 12 mm 36 mm
2028452 SuperPlus 5t 1.5m 5000 kg 59 mm 1 kg/m 1.5 kg 1 m 1.5 m Red 13 mm 39 mm
2028453 SupraPlus 5t 2m 5000 kg 59 mm 1 kg/m 2 kg 1 m 2 m Red 13 mm 39 mm
2028454 SupraPlus 5t 2.5m 5000 kg 59 mm 1 kg/m 2.5 kg 1 m 2.5 m Red 13 mm 39 mm
2028455 SupraPlus 5t 3m 5000 kg 59 mm 1 kg/m 3 kg 1 m 3 m Red 13 mm 39 mm
2028456 SupraPlus 5t 4m 5000 kg 59 mm 1 kg/m 4 kg 1 m 4 m Red 13 mm 39 mm
2028457 SupraPlus 5t 5m 5000 kg 59 mm 1 kg/m 5 kg 1 m 5 m Red 13 mm 39 mm
2028458 SupraPlus 5t 6m 5000 kg 59 mm 1 kg/m 6 kg 1 m 6 m Red 13 mm 39 mm
2028459 SupraPlus 5t 8m 5000 kg 59 mm 1 kg/m 8 kg 1 m 8 m Red 13 mm 39 mm
2028460 SupraPlus 6t 1.5m 6000 kg 65 mm 1.3 kg/m 1.95 kg 1 m 1.5 m Brown 14 mm 42 mm
2028461 SupraPlus 6t 2m 6000 kg 65 mm 1.3 kg/m 2.6 kg 1 m 2 m Brown 14 mm 42 mm
2028462 SupraPlus 6t 2.5m 6000 kg 65 mm 1.3 kg/m 3.25 kg 1 m 2.5 m Brown 14 mm 42 mm
2028463 SupraPlus 6t 3m 6000 kg 65 mm 1.3 kg/m 3.9 kg 1 m 3 m Brown 14 mm 42 mm
2028464 SupraPlus 6t 4m 6000 kg 65 mm 1.3 kg/m 5.2 kg 1 m 4 m Brown 14 mm 42 mm
2028465 SupraPlus 6t 5m 6000 kg 65 mm 1.3 kg/m 6.5 kg 1 m 5 m Brown 14 mm 42 mm
2028472 SupraPlus 6t 6m 6000 kg 65 mm 1.3 kg/m 7.8 kg 1 m 6 m Brown 14 mm 42 mm
2028473 SupraPlus 6t 7m 6000 kg 65 mm 1.3 kg/m 9.1 kg 1 m 7 m Brown 14 mm 42 mm
2028474 SupraPlus 6t 10m 6000 kg 65 mm 1.3 kg/m 13 kg 1 m 10 m Brown 14 mm 42 mm
2028475 SupraPlus 8t 1.5m 8000 kg 68 mm 1.7 kg/m 2.55 kg 1.5 m 1.5 m Blue 17 mm 51 mm
2028476 SupraPlus 8t 2m 8000 kg 68 mm 1.7 kg/m 3.4 kg 1.5 m 2 m Blue 17 mm 51 mm
2028477 SupraPlus 8t 2.5m 8000 kg 68 mm 1.7 kg/m 4.25 kg 1.5 m 2.5 m Blue 17 mm 51 mm
2028478 SupraPlus 8t 3m 8000 kg 68 mm 1.7 kg/m 5.1 kg 1.5 m 3 m Blue 17 mm 51 mm
2028479 SupraPlus 8t 4m 8000 kg 68 mm 1.7 kg/m 6.8 kg 1.5 m 4 m Blue 17 mm 51 mm
2028480 SupraPlus 8t 5m 8000 kg 68 mm 1.7 kg/m 8.5 kg 1.5 m 5 m Blue 17 mm 51 mm
2028481 SupraPlus 8t 6m 8000 kg 68 mm 1.7 kg/m 10.2 kg 1.5 m 6 m Blue 17 mm 51 mm
2028482 SupraPlus 8t 7m 8000 kg 68 mm 1.7 kg/m 11.9 kg 1.5 m 7 m Blue 17 mm 51 mm
2028483 SupraPlus 8t 8m 8000 kg 68 mm 1.7 kg/m 13.6 kg 1.5 m 8 m Blue 17 mm 51 mm
