GrabiQ container hook
Professional
GrabiQ container hook
Container hook
Professional
Item Number: 2008690
GrabiQ Container Hook 12.5t vertical
Container hook, WLL 12500 kg, light yellow, 90°
- Grade 100 with 25% higher load capacity than Grade 80
- The robust components have a low degree of wear due to the high resistance of the material
Select Model
Please contact customer service for purchase or more information
Steel grade 100
Made from steel grade 100 for enhanced strength and increased performance under extreme conditions.
+ 25% higher load capacity
Modular system
Easily replace individual parts
If parts become damaged, you do not have to replace the whole equipment. This minimises purchasing costs and increases safety.
Product Technical Information
-
WLL kg
12500 kg -
Weight Net
3.8 kg -
WLL t
12.5 t -
Grade
100 -
Safety Factor
4:1 -
Dimension L
187 mm -
Norms
EN 1677 -
Temperature Range
-40° C to + 200° C -
Dimension G
75 mm -
Dimension H
47 mm -
Dimension A
25 mm -
Dimension B
46 mm -
Dimension E
70 mm -
Colour
Neon yellow -
Main Material
Steel -
Connection Type
Eye -
Hook Type
Container Hook -
Packaging Unit (PU)
pcs -
Packaging Unit (PU) Content
1
Technical Drawings
Variants information
| Item Number | Item Name | Container Hook Orientation |
|---|---|---|
| 2008690 | GrabiQ Container Hook 12.5t vertical | 90° |
| 2008691 | GrabiQ Container Hook 12.5t right | 45°, right |
| 2008692 | GrabiQ Container Hook 12.5t left | 45°, left |
