Powerform 6 LHOL

Powerform 6 LHOL

High Performance Compacted Strands Products

Item Number: 2023380
SSID ERP Code: UM6X36CO-IWd10.0ZS1960G
POWERFORM 6X36 10MM LHOL
USHA 10MM POWERFORM 6X36 COMPACTED IWRC LHOL 1960 GALV
  • Excellent Fatigue Life due to good sheave contact.
  • High Breaking Load.
  • Crush resistant & low elongation.
  • Plastic inside of rope covered the IWRC giving consistent core performance.
  • LHOL - Left Hand Ordinary Lay.

Select Model

All wire rope that we supply are only high quality and certified products according to International Standard of BS EN 12385, API Spec 9A, ISO 2408 and SNI.

These wire Rope are manufactured by a company that has ISO 9001:2015 certification and also have 3rd party certification from ABS, DNV-GL and Lloyds.

Recommendations for Use

Do not use damaged wire ropes and slings with defects, such as wire breaks, bulges, bruises, kinks, severed core, heavy wear, rust damage or others. Do not exceed the specified load carrying capacity (WLL). Do not strike at a tilt angle exceeding 60°. Do not use wire ropes with broken strands. Do not use in contact with chemicals. Sling ropes may only be used for lifting and transporting loads and only by instructed persons. The regulation on the safe use of cranes (Crane Regulation) must be observed without fail (Suva-Form.1420. d).

Product Technical Information

  • Temperature Range: -40° C to + 100° C
  • Main Material: Steel
  • Packaging Unit (PU): pcs
  • Packaging Unit (PU) Content: 1

Item Number Item Name Rope Diameter Minimum Breaking Force [Kn] Minimum Breaking Force [Tn]
2023380
SSID ERP Code: UM6X36CO-IWd10.0ZS1960G 		POWERFORM 6X36 10MM LHOL 10 mm 85.7 kN 8.7 t
2023381
SSID ERP Code: UM6X36CO-IWd11.0ZS1960G 		POWERFORM 6X36 11MM LHOL 11 mm 98.6 kN 10.1 t
2023382
SSID ERP Code: UM6X36CO-IWd12.0ZS1960G 		POWERFORM 6X36 12MM LHOL 12 mm 114 kN 11.6 t
2023383
SSID ERP Code: UM6X36CO-IWd13.0ZS1960G 		POWERFORM 6X36 13MM LHOL 13 mm 140 kN 15 t
2023384
SSID ERP Code: UM6X36CO-IWd14.0ZS1960G 		POWERFORM 6X36 14MM LHOL 14 mm 147 kN 17.3 t
2023385
SSID ERP Code: UM6X36CO-IWd15.0ZS1960G 		POWERFORM 6X36 15MM LHOL 15 mm 170 kN 19.9 t
2023386
SSID ERP Code: UM6X36CO-IWd16.0ZS1960G 		POWERFORM 6X36 16MM LHOL 16 mm 195 kN 22.2 t
2023387
SSID ERP Code: UM6X36CO-IWd17.0ZS1960G 		POWERFORM 6X36 17MM LHOL 17 mm 218 kN 25.1 t
2023388
SSID ERP Code: UM6X36CO-IWd18.0ZS1960G 		POWERFORM 6X36 18MM LHOL 18 mm 246 kN 28.1 t
2023389
SSID ERP Code: UM6X36CO-IWd19.0ZS1960G 		POWERFORM 6X36 19MM LHOL 19 mm 276 kN 31 t
2023390
SSID ERP Code: UM6X36CO-IWd20.0ZS1960G 		POWERFORM 6X36 20MM LHOL 20 mm 304 kN 34.1 t
2023391
SSID ERP Code: UM6X36CO-IWd22.0ZS1960G 		POWERFORM 6X36 22MM LHOL 22 mm 335 kN 40.8 t
2023392
SSID ERP Code: UM6X36CO-IWd24.0ZS1960G 		POWERFORM 6X36 24MM LHOL 24 mm 400 kN 49.8 t
2023393
SSID ERP Code: UM6X36CO-IWd26.0ZS1960G 		POWERFORM 6X36 26MM LHOL 26 mm
2023394
SSID ERP Code: UM6X36CO-IWd28.0ZS1960G 		POWERFORM 6X36 28MM LHOL 28 mm 578 kN 67 t
2023395
SSID ERP Code: UM6X36CO-IWd30.0ZS1960G 		POWERFORM 6X36 30MM LHOL 30 mm 657 kN 77.2 t
2023396
SSID ERP Code: UM6X36CO-IWd32.0ZS1960G 		POWERFORM 6X36 32MM LHOL 32 mm 757 kN 86.2 t
2023397
SSID ERP Code: UM6X36CO-IWd34.0ZS1960G 		POWERFORM 6X36 34MM LHOL 34 mm 846 kN 93.4 t
2023398
SSID ERP Code: UM6X36CO-IWd36.0ZS1960G 		POWERFORM 6X36 36MM LHOL 36 mm 1065 kN 109 t
2023399
SSID ERP Code: UM6X36CO-IWd38.0ZS1960G 		POWERFORM 6X36 38MM LHOL 38 mm 1165 kN 119 t
2023400
SSID ERP Code: UM6X36CO-IWd40.0ZS1960G 		POWERFORM 6X36 40MM LHOL 40 mm 1295 kN 132 t
2023401
SSID ERP Code: UM6X36CO-IWd42.0ZS1960G 		POWERFORM 6X36 42MM LHOL 42 mm 1425 kN 145 t
2023402
SSID ERP Code: UM6X36CO-IWd44.0ZS1960G 		POWERFORM 6X36 44MM LHOL 44 mm 1505 kN 153 t
2023403
SSID ERP Code: UM6X36CO-IWd46.0ZS1960G 		POWERFORM 6X36 46MM LHOL 46 mm 1665 kN 170 t
2023404
SSID ERP Code: UM6X36CO-IWd48.0ZS1960G 		POWERFORM 6X36 48MM LHOL 48 mm 1885 kN 192 t
2023405
SSID ERP Code: UM6X36CO-IWd50.0ZS1960G 		POWERFORM 6X36 50MM LHOL 50 mm 1975 kN 201 t
2023406
SSID ERP Code: UM6X36CO-IWd52.0ZS1960G 		POWERFORM 6X36 52MM LHOL 52 mm 2135 kN 218 t
2023407
SSID ERP Code: UM6X36CO-IWd54.0ZS1960G 		POWERFORM 6X36 54MM LHOL 54 mm 2325 kN 237 t
2023408
SSID ERP Code: UM6X36CO-IWd56.0ZS1960G 		POWERFORM 6X36 56MM LHOL 56 mm
2023409
SSID ERP Code: UM6X36CO-IWd58.0ZS1960G 		POWERFORM 6X36 58MM LHOL 58 mm 2650 kN 270 t
2023410
SSID ERP Code: UM6X36CO-IWd60.0ZS1960G 		POWERFORM 6X36 60MM LHOL 60 mm 2810 kN 286 t
